The entry level to the Merida road bike range.
The entry level to the Merida road bike range.
Merida

Merida Scultura Rim 100 Gravel Bike in Blue/Green Clear Coat/Silver

€1,140.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Merida Scultura Rim 100 Gravel Bike in Blue/Green Clear Coat/Silver

Season:2026

Brand:Merida

Code:P-R270

The entry level to the Merida road bike range.

Technical Information
  • Frame
    Lite : aluminium; BSA BB Standard; 100 x 9mm / 135 x 9mm axle standard; max. tyre size: 700 x 25C
  • Fork
    Scultura Rim CF2; 700x25C max. tyre size
  • Headset
    Merida M2339 Neck
  • Stem
    Merida Comp CC; material: aluminium; 31.8 mm diameter; -7 degree rise; Length: (XXXXS-XS) - 80mm, S - 90mm, (S/M-M/L) - 100mm, (L-XL) - 110mm
  • Handlebar
    Merida Expert SL; material: aluminium; (XXXS-S) - 380mm wide, (M-L) - 400mm wide, XL - 420mm wide
  • Grip
    Merida Road Comp
  • Brake Type
    Calliper
  • Brake Lever
    Shimano CUES
  • Brake Calipers
    Front: Lee Chi ROAD Dual Pivot Rear: Lee Chi ROAD Dual Pivot
  • Tyres
    Front: Maxxis Pursuer; 700x25C; kevlar bead Rear: Maxxis Pursuer; 700x25C; kevlar bead
  • Wheel Size
    700c
  • Wheels
    Rims: Merida Comp SL; 17mm inner rim width; 20mm rim depth; material: aluminium; not Tubeless ready Spokes: Black stainless Front Hub: Road seal bearing; 100x9mm; 24 Spoke Rear Hub: Road seal bearing; 130x9mm; 28 Spoke
  • Speeds
    18
  • Front Derailleur
    Shimano CUES U6030
  • Rear Derailleur
    Shimano CUES; SGS 9S
  • Shift Levers
    Front: Shimano CUES U3030-L, Rear: Shimano CUES U3030-9R
  • Chain
    KMC M700
  • Cassette
    SunRace U98; 11-36 teeth; 9 speed
  • Chainset
    Prowheel; 50-34 tooth chainset; Crank length: (XXXXS-XS) - 165mm, (S-M/L) - 170mm, (L-XL) - 175mm
  • Bottom Bracket
    FSA TH-7420ST, Cartridge Bearing
  • Pedals
    Not included
  • Saddle
    Merida Comp SL; 25% recycled material; V-mount
  • Seat Post
    Merida Comp CC; 27.2mm diameter; in-line; material: aluminium
